M_VideoTrackerCommon::IService Class Reference

Inheritance diagram for M_VideoTrackerCommon::IService:

Public Member Functions
virtual	~IService ()
virtual void	CmdLoadParameterSet (M_Common::BoundedStringType const &ParameterSetName)
virtual void	CmdSelectObject (M_Common::HorizontalDirectionOptionalType const &Horizontal, M_Common::VerticalDirectionOptionalType const &Vertical, M_Common::SphericalPositionOptionalType const &Position)
virtual void	ConfigVtTrackInfo (M_Common::ObjectIdType const &KeyId, M_Sensor::SensorDetectionType const &Detection, bool IsRemoved)
Public Member Functions inherited from M_Sensor::IService
virtual void	CmdIsSensorAlive ()
virtual void	CmdDeleteTracks (M_Common::ObjectIdListType const &KeyIdList)
virtual void	CmdDeleteAllTracks ()
virtual void	CmdDeactivateSensor (bool Deactivate)
virtual void	ConfigSensorCoverage (M_Common::ObjectIdType const &KeyId, M_Sensor::SensorCoverageType const &Coverage, bool IsRemoved)
virtual void	CmdSetPreset (M_Common::ObjectIdOptionalType const &Preset)
virtual void	CmdLockOnTracks (M_Common::ObjectIdListType const &KeyIdList)

Detailed Description

VideoTracker Service interface. Contains operations that a client can command the VideoTracker Service to perform.

Multi-Mode Tracker IService Overview

Constructor & Destructor Documentation

~IService()

M_VideoTrackerCommon::IService::~IService ( )

virtual

Reimplemented from M_Sensor::IService.

Member Function Documentation

CmdLoadParameterSet()

void M_VideoTrackerCommon::IService::CmdLoadParameterSet ( M_Common::BoundedStringType const &  ParameterSetName )

virtual

Let VideoTracker load a set of preconfigured parameters. E.g. project- or scenario-specific parameters.

Parameters

ParameterSetName

Name of parameter set to be loaded.

CmdSelectObject()

void M_VideoTrackerCommon::IService::CmdSelectObject ( M_Common::HorizontalDirectionOptionalType const &  Horizontal, M_Common::VerticalDirectionOptionalType const &  Vertical, M_Common::SphericalPositionOptionalType const &  Position  )

virtual

Track object selection. Use case: Select ATR objects for Lock/Lead-On by cursor keys or touch/mouse. If all values are empty, the selection is removed. If Position is filled, Horizontal and Vertical are ignored. Position where the selection applies w.r.t. image center.

Parameters

Horizontal	Select next object in given direction.
Vertical	Select next object in given direction.
Position	Position where the selection applies.

ConfigVtTrackInfo()

void M_VideoTrackerCommon::IService::ConfigVtTrackInfo ( M_Common::ObjectIdType const &  KeyId, M_Sensor::SensorDetectionType const &  Detection, bool  IsRemoved  )

virtual

Inform VideoTracker about external object information for an object that is already tracked. (A-priori).

Parameters

KeyId	Identifier of an existing currently tracked object.
Detection	A-priori object information
IsRemoved	Indicates if info has been removed.
